| 1. Cabinet Parameter | ||||||
| Module Size【(W)x(H) mm】 | Pixel Pitch (mm) | LED type | Configuration | |||
| 320*160 | 1.53 | SMD 1212 | 208*104 | pixels | ||
| 2. Complete solution | ||||||
| NO. | Model | P1.53 | ||||
| 1 | Pixel pitch | 1.53mm | ||||
| 2 | LED configuration | SMD 1212 | ||||
| 3 | Module size | 320*160mm | ||||
| 4 | Pixel matrix per Module | 208*104 dots | ||||
| 5 | Pixel density | 422500（pixels/sq.m.） | ||||
| 6 | Screen size | 640mm*1920mm | ||||
| 7 | Cabinet Resolution | 416*1248 dots | ||||
| 8 | Refresh rate | ≥3840hz | ||||
| 9 | Brightness | 900-1000 cd | ||||
| 10 | Ingress Protection | IP40(Fron/Rear) | ||||
| 11 | Optimal Horizontal Viewing Angle | ≥160° | ||||
| 12 | Optimal Vertical Viewing Angle | ≥160° | ||||
| 13 | AC Input Voltage | AC 110V/220V±10%,50Hz/60Hz | ||||
| 14 | Gray Level | 14-16bit | ||||
| 15 | Scan mode | 1/52 scan | ||||
| 16 | Working Temperature | -40 -60(℃) | ||||
| 17 | Operating Humidity | 10%~95% non-condensing | ||||
| 18 | Video Format | Support RM,FLV,AVI,MP4 and other mainstream video formats | ||||
| 19 | Picture Format | Support JPG,PNG,and other image formats | ||||
| 20 | Controllnterface | HDMI*1,USB2.0*2,AUX*1 | ||||
| 21 | Operating Equipment | Phone,iPad,PC | ||||
| 22 | Life Time | ≥100000(Hours) | ||||
