Product Details
Place of Origin: SHENZHEN
Brand Name: HSCXLED
Certification: KC CE ROHS FCC CCC ISO9001
Model Number: P0.9/P1.25/P1.5/P1.8
Payment & Shipping Terms
Minimum Order Quantity: 1Set
Packaging Details: Fight case/Wooden case/Honeycomb Box
Delivery Time: 15-35 workdays
Payment Terms: L/C,T/T
Supply Ability: 10000Set
Highlight: Home Wall Led Screen, Home Theater Display Advertising Screen, Indoor LED Display
Produce Name: | HD LED Display | Pixels: | P0.9/P1.25/P1.5/P1.8 |
Tube Chip Color: | INDOOR FULL COLOR | Pixel Configuration: | COB 1R 1G 1B |
Module Dimension: | 150x168.75mm | Cabinet Dimension: | 600x337.5x25mm |
Cabinet Material: | Die Casting Aluminum | Cabinet Weight: | 5.2KG |
Refresh Rate: | 3840Hz/7680Hz | Viewing Angle: | 160°, 170°, 180° |
Power Supply: | 100-240V AC | Operating Temperature: | -20℃~60℃ |
Service Access: | Full Front Access | Type: | Micro Cob 8K P0.9 P1.2 P1.5 Ultra Thin Led Screen |
Indoor LED Display (Indoor Screen)
Ultra-high definition display, high contrast ratio and vivid color reproduction, presenting realistic image details; Simple and quick installation, modular splicing design, easy to assemble and disassemble by a small team.
Customizable size, resolution and display effect, adapting to different indoor spaces such as shopping malls, conference rooms and exhibition halls; In-stock availability, quick shipment to meet urgent indoor display demands.
Low noise operation, energy-saving design, suitable for long-term indoor use without disturbing the environment; Lightweight and thin body, saving installation space, matching various indoor decoration styles.
High refresh rate, no flicker, eye-friendly for long-time viewing; Supports seamless splicing, realizing large-size display without image distortion. We have professional consultants to provide you with customized solutions.
Cob Indoor Led Screen Specification:
| Indoor Small Pixel Pitch HD LED Video Wall LED Display Screen | ||||
| Item | P0.93mm | P1.25mm | P1.56mm | P1.87mm |
| Pixel Pitch | 0.93mm | 1.25mm | 1.56mm | 1.87mm |
| LED Chip | MiniLED | SMD1010 | SMD1212 | SMD1515 |
| Module Size | 300x168.75mm | |||
| Module Resolution | 320x180pixel | 240x135pixel | 192x108pixel | 160x90pixel |
| Cabinet Size | 600x337.5mm | |||
| Cabinet Resolution | 640*360pixel | 480x270pixel | 384x216pixel | 320x180pixel |
| Scanning mode | 1/60 | 1/60 | 1/64 | 1/45 |
| Maintenance | Full front service | |||
| Brightness | ≥800CD | |||
| Refresh rate | ≥3840Hz | |||
| Viewing angle | 160° (V/H) | |||
| Contrast ratio | 5000:01:00 | |||
| Working voltage(input) | 100-240V, 50/60Hz | |||
| Max./Avg.Power consumption | Max: 500W/M2 Ave: 165-260W/M2 | |||
| Working temperature | -20°C-50°C | |||
| IP ratings | IP45 | |||
| Signal output | HDMI/VGA/DVI/DP/SDI... | |||
| Life Span | 100000hours | |||
| Certification | KC/CE/FCC/CCC/ROHS/ISO9001 | |||
Ultra Thin Led Screen Indoor Curved Led Display Pantalla Led Video Wall for Home Theater
Cob Indoor Led Screen Features:
1. Gorgeous Picture: Non-reflective screen, which brings better viewing experience.
2. Perfect Image: Our products use special IC for LED which owns high refresh rate and achieves no shadows
3. Light Weight: The cabinet uses aluminum profile stitching weighing 5-8kg, which is light and non- corrosive.
4. Elegant Appearance: We adopt CNC processing technique to produce standard module and cabinet which can easily do seamless assemble.
5. Easy Setup: Back modules are made easier for connection.
6. Totally front service design. Saving space and maintenance cost.
7.Efficient Heat Dissipation:High precision seamless splicing, silent and fanless design, die-cast aluminum body;
8.Full flip-chip COB integrated packaging, high protection, high reliability, high environmental adaptability;
Full front maintenance, featuring hot-swappable modules, and overall rigid connection.
